Hikvision DS-A81016S

DSA81016S

New product

16-slot Single Controller Storage

  • Economical and Stable Hardware Platform
  • HDD detection and repair/RAID optimization
  • Surveillance-specialized direct storage (Direct Streaming mode+IP SAN mode)

More details

In Stock

Whatsapp MB WhatsApp

Rs 967,200

Call | Whatsapp

Karachi: +92-300-0778713 , +92-300-8265122 , +92-213-2270926 , +92-213-2270927

For Information & Quotation Email: sales@mbcommunication.com.pk

More info

Product Information:

Hikvision DS-A81016S Features and Benefits

Features:

Hikvision DS-A81016S Description

16-slot Single Controller Storage

  • Economical and Stable Hardware Platform
  • HDD detection and repair/RAID optimization
  • Surveillance-specialized direct storage (Direct Streaming mode+IP SAN mode)
  • Advanced data protection (synchronous backup of key information in system disks)
  • Energy efficient and user-friendly UI

Overview

The Hikvision DS-A81016S Network Storage Device supports 16 HDDs, each with a 4TB capacity, to store up to 180 channels of 4CIF real-time recording. It supports iSCSI/NFS/CIFS/FTP/HTTP/AFP protocols, RAID 0, 1, 3, 5, 10, 50, and HDD hot-swap functionality. The device features dual gigabit network interfaces.

64-bit RISC processor
Modularization and redundant power design

Specification

Processor 64-bit multicore processor
Buffer 4 GB (expandable to 8 GB)
Recording 256-channel (2 Mb/s)
Operating System Windows, Linux, Solaris, HP-UX, AIX, Mac OS
Audio Encoding OggVorbis
Audio Output 1-channel BNC (Linear level, 600 Ohms)
Slot 16
Interface SATA
Supported HDD Capacities 1, 2, 3, 4 TB
Disk Management S.M.A.R.T (Self-Monitoring, Analysis and Reporting Technology)
LUNs NAS Volume, iSCSI Volume, Record Volume
Data Protection WORM tamperproof , Real-time backup of system information, LUN clone
Recording type Continuous/ Manual / Main and Sub Stream / Motion / Sensor
Backup Recording: Local backup
Remote backup
Protection Lock key video file for protection, N+1 hot spare system, ANR, video loss alarm
Search Modes By time/type
Download Download Mode: Quick download, batch download, segment download, merging download
Device Management Management Method: Web-based GUI, CLI serial port, integrated management of multiple units
Alarm Type Sound, Flash LED, Email, SMS, Warning on device management page
Logs Auto-down load by USB flash drive, Remote backup via web browsing
Protocols RTSP/ONVIF/PSIA/iSCSI/NFS/CIFS/FTP/HTTP/AFP
Ports Data Port: 2 (can be expanded to 6), 10M/100M/1000M self-adaptive Ethernet interface
Management: 1, 10M/100M/1000M self-adaptive Ethernet interface
SAS Expansion: 1, 6 Gb/s
1 x VGA output
COM Interface: 2 (1 for hyper terminal and 1 for mobile phone alarm/UPS)
2 x USB
Power Supply Redundant (1 + 1)
Single power available
Power Consumption Maximum 460 W (with hard disk, redundant power)
Maximum 400 W (with hard disk, single power)
Temperature Operating: 41 to 104°F / 5 to 40°C
Storage: -4 to 158°F / -20 to 70°C
Humidity Operating: 20 to 80% RH (non-freezing, non-condensing)
Storage: 5 to 90% RH (non-freezing, non-condensing)
Chassis Standard 19" / 48.2 cm rack-mounted 3U chassis
Dimensions 17.3 x 5.19 x 18.89" / 440 x 132 x 480 mm
Weight Approximately 44 lb / 20 kg (without hard disk, redundant power)
Approximately 40.7 lb / 18.5 kg (without hard disk, single power)
