Specification

• Door Station/System Parameters
• Operation System: Embedded Linux operation system
• Flash: 32 MB
• RAM: 128 MB

• Door Station/Video Parameters
• Camera: 2MP HD camera
• Night Vision: Low illumination IR supplement mode:3 m
• Backlight Compensation: Support
• Digital Noise Reduction: Support
• WDR: True WDR
• Field Of View: Horizontal: 129° Vertical: 75°
• Video Compression Standard: H.264
• Stream: Main stream: 1080p@30fps, 720p@25fps Sub stream: D1@25fps
• Motion Detection: Support
• Flash-Avoid Frequency: 50 Hz, 60 Hz

• Door Station/Audio Parameters
• Audio Input: Built-in omnidirectional microphone
• Audio Output: Built-in loudspeaker
• Audio Quality: Noise suppression and echo cancellation
• Audio Compression Standard: G.711 U
• Audio Compression Rate: 64 Kbps
• Audio Intercom: Two-way audio communication

• Door Station/Network Parameters
• Network Protocol: TCP/IP, RSTP
• Wired Network: 10/100 Mbps Ethernet

• Door Station/Device Interfaces
• RS-485: 1
• Alarm Input: 4
• Debugging Port: 1
• Grounding: 1
• TAMPER Switch: 1

• Door Station/General
• Power Consumption: ＜ 10 W
• Working Temperature: e-40° C to 53° C(-40° F to 127.4° F)
• Working Humidity: 10% to 95%
• Dimension: 174 mm × 91 mm × 29 mm
• Installation: Surface mounting/ Flush mounting
• Protection Level: IP65, IK08
• Indicator: 3
• Power Supply

  IEEE802.3af, standard PoE

  12 VDC

• Indoor Station/System Parameters
• Operation System: Embedded Linux operation system
• Memory: 128 MB
• Flash: 32 MB

• Indoor Station/Display Parameters
• Display Screen: 7-inch colorful TFT screen
• Display Resolution: 1024 × 600
• Operation Method: Capacitive touch screen

• Indoor Station/Audio Parameters
• Audio Input: Built-in omnidirectional microphone
• Audio Output: Built-in loudspeaker
• Audio Quality: Noise suppression and echo cancellation
• Audio Compression Standard: G.711 U
• Audio Compression Rate: 64 Kbps

• Indoor Station/Network Parameters
• Wired Network: 10/100 Mbps self-adaptive
• Wireless Network: Wi-Fi 802.11 b/g/n
• Protocol: TCP/IP, SIP, RTSP
• RS-485: 1 RJ-45 10/100 Mbps self-adaptive

• Indoor Station/Device Interfaces
• RS-485: 1
• Alarm Input: 8-ch alarm inputs
• Relay Output: 2
• TF Card: Max to 32 G, SD 2.0 or lower version

• Indoor Station/General
• Power Consumption: ≤ 6 W
• Working Temperature: ‘-10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity: 10% to 90%
• Dimension (L X W X H)

  200 mm × 140 mm × 15.1 mm (7.9" ×

  5.5 × 0.6")"
