Camera

Image Sensor

1/2.8" progressive scan CMOS

Min. Illumination

Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON)

Shutter Speed

1/3 s to 1/100, 000 s

Slow Shutter

Yes

Auto-Iris

No

Day &Night

IR cut filter

Digital Noise Reduction

3D DNR

WDR

DWDR

Angle Adjustment

Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360°

Lens

Focal Length

2.8 mm

Aperture

F2.0

Focus

Fixed

FOV

horizontal FOV 114°, vertical FOV 62°, diagonal FOV 135°

Lens Mount

M12

IR

IR Range

Up to 30 m

Wavelength

850 nm

Compression Standard

Video Compression

Main stream: H.265/H.264

Sub stream: H.265/H.264/MJPEG

H.264 Type

Main Profile/High Profile/Baseline Profile

H.265 Type

Main Profile

Video Bit Rate

32 Kbps to 8 Mbps

Smart Feature-set

Region of Interest

1 fixed region for main stream


Max. Resolution

1920 × 1080

Main Stream

Max. Frame Rate

50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)

60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub-stream

Max. Frame Rate

50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)

60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Image Enhancement

BLC, 3D DNR

Image Settings

Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser

Day/Night Switch

Auto, scheduled, day, night

Network

Alarm Trigger

Motion detection, video tampering alarm, illegal login

Protocols

TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS,  UDP

General Function

Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark

Firmware Version

V5.5.70

API

ONVIF (PROFILE S), ISAPI

Simultaneous Live View

Up to 6 channels

User/Host

Up to 32 users

3 levels: Administrator, Operator and User

General

Operating Conditions

-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)

Power Supply

12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3)

Power Consumption and Current

12 VDC, 0.3 A, max: 3.5 W

PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 4.5 W

Ingress Protection

IP67

Material

Camera body: metal, bottom base : plastic

Dimensions

Camera: Ø 110 mm × 93.2 mm (4.3" × 3.7")

With package: 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")

Weight

Camera: approx. 360 g (0.8 lb.)  With package: approx. 610 g (1.3 lb.)
