Specification

• Camera
• Image Sensor: 2 MP CMOS
• Max. Resolution: 1920 (H) × 1080 (V)
• Minimum Illumination: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light ON
• Shutter Time: PAL: 1/25 s to 1 / 50,000 s; NTSC: 1/30 s to 1 / 50,000 s
• Day And Night: 24/7 Color Imaging
• Angle Adjustment: Pan: 0 ° to 360 °, Tilt: 0 ° to 75 °, Rotation: 0 ° to 360 °
• System Signal: PAL / NTSC
• Slow Shutter: Max. 16 times
• Luminous Alarm: Solid Light Alarm (White Light)

• Lens
• Lens: 2.8mm, 3.6mm, 6mm fixed focal lens
• Focal Length & FOV

  2.8mm, horizontal FOV: 98 °, vertical FOV: 52 °, diagonal FOV: 116 °

  3.6mm, horizontal FOV: 77 °, vertical FOV: 42 °, diagonal FOV: 91 °

  6mm, horizontal FOV: 51 °, vertical FOV: 28 °, diagonal FOV: 59 °

• Lens Mount: M12

• Illuminator
• Supplementary Light Type: White Light
• Supplemental Light Range: Up to 40 m
• Smart Supplement Light: And it is on

• Image
• Image Parameter Switch: STD / HIGH-SAT / HIGHLIGHT
• Picture Settings: Brightness; Contrast; Mirror; Defective Pixel Correction; Sharpness; Anti-Banding
• Frame Rate

  TVI: 1080p @ 25fps / 30fps

  CVI: 1080p @ 25fps / 30fps

  AHD: 1080p @ 25fps / 30fps

  CVBS: PAL / NTSC

• Day / Night Mode: Colour
• Wide Dynamic Range (WDR): ≥130 dB
• Image Enhancement: WDR; BLC; HLC; Global; HLS
• Privacy Mask: 4 programmable privacy masks
• Noise Reduction: 3D DNR / 2D DNR
• White Balance: Auto / Manual
• White Light: Auto / Off
• AGC: And it is

• Interface
• Video Output: Switchable TVI / AHD / CVI / CVBS

• Event
• Motion Detection: 4 programmable motion areas

• General
• Material: Main body: Metal, Enclosure: Plastic
• Dimension: Φ 109.98 mm × 98.27 mm (Φ 4.33 "× 3.87") (Approx. 348.5 g (0.77 lb.)
• Operating Condition: -40 ° C to 60 ° C (-40 ° F to 140 ° F), Humidity: 90% or less (non-condensing)
• Communication: HIKVISION-C
• Idiom: English
• Power Supply

  12 VDC ± 25%,

  * You are recommended to use one power adapter to supply the power for one camera.

• Consumption: Max. 4.2 W

• Certifications
• Protection: IP67
