Motion Detection 2.0

Human/Vehicle Analysis

Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;

Quick search by object or event type is supported;

Perimeter Protection

Human/Vehicle Analysis

Up to 2-ch

Facial Detection

Facial Detection and Capture

Face picture detection, face picture search

Recording

Video Compression

H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264

Encoding Resolution

When 1080p Lite mode is not enabled:
3K lite / 5MP lite/ 4MP lite / 1080p / 720p
When 1080p Lite mode is enabled:
3K lite/ 5MP lite / 4MP lite / 1080p lite / 720p lite

Frame Rate

Main stream:

When 1080p Lite mode not enabled:
For 3K stream access: 3K lite @ 12fps; 4 MP lite / 1080p @ 15fps; 720p @ 20fps
For 5 MP stream access: 5 MP lite@12fps; 4 MP lite / 1080p @ 15fps; 720p @ 20fps
For 4 MP stream access: 4 MP lite / 1080p @ 15fps; 720p @ 25fps (P) / 30fps (N)
For 1080p stream access: 1080p / 720p @ 15fps; VGA @ 25fps (P) / 30fps (N)
For 720p stream access: 720p @ 25fps (P) / 30fps (N)
When 1080p Lite mode enabled:
3K lite / 5MP lite@12fps; 4 MP lite @ 15fps; 1080p lite/720p lite @ 25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF @ 12fps; CIF @ 25fps (P)/30fps (N)

Video Bitrate

32 Kbps to 6 Mbps

Dual-stream

Support

Stream Type

Video, Video & Audio

Audio Compression

G.711u

Audio Bitrate

64 Kbps

Video and Audio

IP Video Input

1ch (up to 5-ch)

Enhanced IP mode on:

1ch (up to 6-ch), each up to 4 Mbps Up to 6 MP resolution

Analog Video Input

4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

HDTVI Input

3K @ 20 fps, 5MP @ 20 fps, 4MP @ 30 fps, 4MP @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps, 720p @ 30 fps, 720p @ 25 fps

AHD Input

5 MP @ 20 fps,4MP @ 30 fps, 4 MP @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps, 720p @ 30fps, 720p @ 25 fps

HDCVI Input

5 MP @ 20 fps, 4MP @ 30 fps, 4MP @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps, 720p @ 30fps, 720p @ 25 fps

CVBS Input

Support

HDMI Output

1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

VGA Output

1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz

Video Output Mode

HDMI/VGA simultaneous output

Audio Input

1-ch, RCA (2.0 Vp-p, 1 KΩ)

4-ch via coaxial cable

Audio Output

1-ch, RCA (Linear, 1 KΩ)

Two-Way Audio

1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)

Synchronous Playback

4-ch

Network

Total Bandwidth

72 Mbps

Remote Connection

32

Network Protocol

TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF

Network Interface

1, RJ45 10/100 Mbps self-adaptive Ethernet interface

Auxiliary Interface

SATA

1 SATA interface

Capacity

Up to 10 TB capacity for each disk

Alarm In/Out

N/A

USB Interface

Real panel: 2 × USB 2.0

General

Power Supply

12 VDC, 1.5 A

Consumption

≤ 8 W (without HDD)

Working Temperature

-10 °C to +55 °C  (+14 °F to +131 °F)

Working Humidity

10% to 90%

Dimension (W × D × H)

200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)

Weight

≤ 1 kg (without HDD, 2.2 lb.)
